Ambient Temperature:-15°C to +40°C
Bearing Type:Deep Groove Ball Bearing
Color:Blue/Grey
Cooling Method:Fan Cooled
Current Type:AC
Dimension (L*W*H):As per model selection
Efficacy:IE2 / IE3
Features:Compact design, High torque transmission, Durable construction
Frequency (MHz):50 / 60 Hz
Horse Power:0.16 to 60 HP
IP Rating:Other, IP55
Motor Type:Helical Geared Motor
Mounting Type:Foot / Flange Mounted
Noise Level:Low Noise
Output Power:0.12 kW to 45 kW
Phase:Three Phase
Poles Number:Other, 2, 4, 6
Power:0.16 HP to 60 HP
Power Rating:0.12 kW to 45 kW
Pressure:Other, Standard Atmospheric
Product Type:Other, Electric Motor
Protect Feature:Other, IP55 enclosures
Rated Frequency:50 Hz
Rated Voltage:415 V
Sealed Type:Other, Totally Enclosed Fan Cooled (TEFC)
Shaft Diameter:As per model
Speed:Up to 3000 RPM
Standard:IS, IEC, DIN
Starting Type:Direct on Line / Star-Delta
Torque:Up to 1200 Nm
Voltage:380V / 415V
Weight:Varies by model
Know More
Keeping in mind the variegated demands of domestic and global markets, our well-reckoned company is engaged in manufacturing Helical Geared Motor . It is made with the help of a team of adroit professionals using qualitative components. Offered motor is highly appreciated by clients for its excellent operational efficiency, low maintenance, robust construction and prolonged functional life. We offer this Helical Geared Motor in different models and configurations to suit clients' requirements.
Product Details
Model Name/Number | NCJF04Y |
Speed | 1400 RPM |
Color | Blue |
Mounting | Flange |
Number Of Poles | 4 |
Power | 1 HP |
This helical geared motor supports both horizontal and vertical installations, making it suitable for a wide range of applications such as conveyors, mixers, material handling systems, and diverse industrial automation setups. Its flexible and rigid coupling options, along with a variety of input flange sizes, cater to numerous integration requirements, ensuring maximum adaptability.
Enhanced Durability & PerformanceHardened and ground alloy steel gears combined with deep groove ball bearings ensure outstanding durability and reliable torque transmission up to 1200 Nm. Operated with synthetic oil lubrication, the geared motor minimizes maintenance needs and optimizes performance, while its robust, compact design guarantees a long operational lifespan even under continuous duty cycles.
Comprehensive Safety & Efficiency FeaturesThe IP55 totally enclosed fan cooled (TEFC) design safeguards the motor against dust and water, supporting continuous safe operation. IE2/IE3 efficiency classes, optional electromagnetic brakes, and the ability to add thermal protection integrate advanced safety and energy-saving functionalities, satisfying strict industrial standards and demands.
FAQ's of Helical Geared Motor:
Q: How is the helical geared motor installed in different applications?
A: The motor can be installed in both horizontal and vertical positions, accommodating foot or flange mounting as required by your application. This versatility allows integration into conveyors, mixers, and other material handling systems.
Q: What benefits does synthetic oil lubrication provide for the motor?
A: Synthetic oil ensures longer lubrication intervals, reduced friction and wear, and optimal performance even under demanding continuous (S1) operations. This helps minimize maintenance and downtime.
Q: When should electromagnetic brake options be considered?
A: Electromagnetic brakes are recommended for applications that require precise stopping or holding, such as in conveyor systems or automated processes, and can be optionally included based on operational needs.
Q: What standards does the helical geared motor conform to?
A: The motor is designed in compliance with IS, IEC, and DIN standards, ensuring reliability, performance, and safety for industrial environments.
Q: Where is the helical geared motor used most effectively?
A: It is particularly effective in industrial machinery such as material handling equipment, mixers, automated conveyor systems, and various forms of industrial automation, owing to its robust construction and efficient power delivery.
Q: What is the process for selecting the correct input flange size and shaft diameter?
A: Input flange size and shaft diameter are determined based on the specific application and model selection. Our technical support team can assist in choosing the appropriate configuration to match your operational needs.
Q: How does the IP55 enclosure protect the motor in industrial environments?
A: The IP55 totally enclosed fan cooled (TEFC) design shields the motor from dust and water ingress, ensuring safe and continuous operation in harsh or demanding conditions.
